GENERAL SPECIFICATIONS
SPECIFICATIONS
11.
12.
13.
"H" Button
Used to enter/exit Data Hold mode.
Holster
Illumination Lamp
Display: 3 1/2-digit LCD, with a max. reading of 1999
Negative Polarity Indication:
Negative sign " - " shown on the display automatically
Sampling Rate: About 2
–
3 times/sec
IP Degree: IP20
Battery: 9 V battery, 6F22 or equivalent, 1 pieces
Low Battery Indication: " " shown on the display
Operating Environment: Temperature: 32 to 104ºF (0 to 40°C)
Relative Humidity: < 75%
Storage Environment: Temperature: 14 to 122ºF (-10 to 50ºC)
Relative Humidity: < 85%
Size: 6 11/16 x 3 3/8 x 1 9/16" (170 x 86 x 40 mm)
Weight: About 10 1/4 oz (291 g) (including battery)
Readings are accurate for a period of one year after calibration at 64
to 82ºF (18 to 28ºC), with relative humidity < 75%.
Accuracy specifications take the form of:
±([% of Reading] + [number of Least Significant Digits])
8
TECHNICAL SPECIFICATIONS
