MEASURING RESISTANCE
CONTINUITY TEST
1.
2.
3.
4.
Connect the black test lead to the "COM" terminal and the red
test lead to the "ΩVmA°F" terminal.
Set the range switch to desired Ω range position.
Connect the test leads across the object to be tested.
Read the reading on the display.
1.
2.
3.
For measurements > 1 MΩ, the meter may take a few
seconds to stabilize reading. This is normal for high
resistance measurements.
When the input is not connected, i.e. at open circuit, "OL"
will be displayed as an overrange indication.
Before test, disconnect all power to the circuit to be tested
and discharge all capacitors thoroughly.
1.
2.
3.
4.
Connect the black test lead to the "COM" terminal and the red
test lead to the "ΩVmA°F" terminal.
Set the range switch to position.
Connect the test leads across the circuit to be tested.
If the resistance is less than about 20 Ω, the built-in buzzer will sound.
Note:
If the magnitude of the current to be measured is not known
beforehand, set the range switch to the highest range first and
then reduce it range by range until satisfactory resolution is
obtained.
Note:
