CHARGING THE BATTERY PACK
WARNING: Use only the
diagnostic charger supplied with the
drill kit to charge the Mastercraft
18 V Ni-Cd battery supplied with the
drill. Charging any other batteries with
this charger may damage the charger,
and possibly cause serious injury.
1. To charge the battery, place the
charger (1) in a dry location near a
120 V AC, 60 Hz electrical outlet
(Fig. 1).
2. Place the battery stem (2) into the
matching cavity (3) in the top of the
charger.
NOTE: Make sure the battery is pressed
fully onto the charger as far as it will go.
3. Plug the battery charger into the
120 V AC, 60 Hz wall receptacle.
NOTE: Do NOT charge batteries when the
work area or the battery temperature is at
or below 0°C (32° F) or above
45°C (113° F).
When the battery charger is plugged into a
“live” receptacle, the battery charger will
begin charging the battery. The red LED
(4) and the green LED (5) on the top of the
charger will indicate the charging status
(Fig. 2).
