MasterCraft 054-1209-2 User Manual

29
WARNING: When servicing, use only Mastercraft
®
replacement parts. The use of
any other parts may create a safety hazard or cause damage to the cordless drill.
Any attempt to repair or replace electrical parts on this cordless drill may create a safety
hazard unless repairs are performed by a qualified technician. For more information, call
the Toll-free Helpline, at 1-800-689-9928.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
440858010
Decorative cover-right
1
2
6597391213
Torx screw ST3.9×12
2
3
4301570101
Housing
1
4
2000380101
Battery pack
1
5
3601820101
Battery lock assembly
1
6
6597391613
Torx screw ST3.9×16
8
7
312999
Swing adjustment knob
1
8
514065
Needle roller
3
9
217034
Vertical axis
1
10
200500
Small bevel gear
2
11
500856
Screw
2
12
237507
Hex nuts
1
13
502001
Hex nuts
1
14
312251
Vertical axis cover
1
15
312244
Vertical positioning wheel
1
16
311758
Holder
1
17
312282
Locking ring
2
18
237217
Positioning ring
1
19
221293
Wave washer
1
20
221210
Small washer
2
21
516008
Ball Φ3
12
22
315933
Ball holder
1
23
316850
Gear box
1
24
5101780101
Ring gear
1
25
205607
Shaft collar
1
26
213772
Planetary shaft
1
27
5101810101
Planetary gear
3
28
221227
Clamp plate
1
29
316838
High/Low speed switch box
1
30
500006
Screw ST2.9×12
4
PARTS LIST
!
