WARNING: When servicing, use only Mastercraft
®
replacement parts. The use of
any other parts may create a safety hazard or cause damage to the angle grinder.
Any attempt to repair or replace electrical parts on this angle grinder may create a safety
hazard unless repairs are performed by a qualified technician. For more information, call
the Toll-free Helpline, at 1-800-689-9928.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
216003
Outside flange
1
2
640000
Abrasive wheel
1
3
216004
Inner flange
1
4
6511401012
Screw M4×10
12
5
504003
Spring washer M4
12
6
5403450101
Wheel guard clamp
1
7
221203
Wave washer
1
8
5403460101
Wheel guard
1
9
6100730101
Output spindle
1
10
513001
Woodruff key
1
11
236044
Gear cover
1
12
221204
Washer
1
13
520033
Bearing 6001
1
14
224305
Bearing clamp A
1
15
6516400812
Screw M4x8
2
16
214908
Bevel gear
1
17
215140
Spindle lock pin
1
18
240801
Spring
1
19
511007
Circlip for shaft 9
1
20
521000
Bearing HK0810
1
21
6701040302
Nut
1
22
155517
Spindle lock button
1
23
6597393013
Screw ST3.9×35
2
24
6597392523
Screw ST3.9×25
2
25
5201800101
Gear housing
1
PARTS LIST
!
