Matrix ClimbMill C50-F User Manual

20
CHAPTER 5: PART REPLACEMENT GUIDE
5.1 SERVICE COVER REPLACEMENT
1) Turn off power and disconnect the cord from the machine.
2) Remove the 2 screws holding the service cover to the side cover (Figure A).
3) Pull up on the service cover to remove it (Figure B & C).
FIGURE A FIGURE B
FIGURE C
