ASSEMBLY

STEP 1 | COUNTER WEIGHT ASSEMBLY INSTRUCTIONS & NOTES

PART 5: COUNTER WEIGHT ASSEMBLY

ID DESCRIPTION QUANTITY

16 M8 Flat Washer 4

27 Counter Weight 2

28 M8 X 20L SHC 4

Install the counter weights as shown.

Tighten to 39 N-m/29 ft-lbs.
