McIntosh RS150 User Manual

9
LOUDSPEAKER SYSTEM
Rear View Labeled
Acoustic Port
For best sound, do not place
the RS150 directly against a
wall. Leave a minimum of two
inches from the wall to enable the
Acoustic Port to function properly.
USB Service Port
Ethernet Port
AC Connector
Figure 6– Rear View
Serial Number
Rear Connecons
Ethernet Port
The Ethernet Port connects your RS150 to your
network’s router using a standard CAT5, CAT5E
or CAT6 cable with an RJ45 connector. Using a
wired connection is one way to access the RS150’s
setup via a browser. For more information, see “The
Browser Interface” on page 10.
AC Connector
Use the supplied AC Power Cord to connect the
RS150 to a live AC outlet.
USB Service Port
The USB port is only for performing service
functions by a qualied service technician. It is not
intended for USB device support or playback.
