McQuay MCK 020A User Manual

Performance Table
A Series (Cooling Only – R22)
Model : MCK020A / MLC020B
Indoor DB Indoor WB Capacity Outdoor DB, ° C
° C ° C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 5.669 5.396 5.152 4.907 4.441 4.119 3.963 3.903 3.855
SC 5.669 5.396 5.152 4.907 4.441 4.119 3.963 3.903 3.855
15 TC 5.897 5.632 5.394 5.157 4.667 4.329 4.165 4.102 4.051
SC 5.586 5.314 5.071 4.828 4.369 4.053 3.899 3.840 3.792
18 TC 6.519 6.274 6.056 5.837 5.283 4.9 4.715 4.643 4.585
SC 5.358 5.09 4.85 4.611 4.173 3.87 3.724 3.667 3.622
19.4 TC 6.809 6.574 6.365 6.155 5.571 5.167 4.971 4.895 4.835
SC 5.252 4.986 4.747 4.509 4.081 3.785 3.642 3.587 3.542
20 TC 6.934 6.681 6.456 6.231 5.639 5.23 5.032 4.956 4.894
SC 5.207 4.924 4.671 4.419 3.999 3.709 3.569 3.515 3.471
22 TC 7.348 7.038 6.761 6.484 5.868 5.443 5.237 5.157 5.093
SC 5.055 4.718 4.418 4.117 3.726 3.456 3.325 3.275 3.234
24 TC 7.763 7.395 7.066 6.737 6.097 5.655 5.441 5.358 5.292
SC 4.903 4.513 4.164 3.815 3.453 3.203 3.082 3.035 2.997
HIGH AMBIENT
Model : MCK025A / MLC025B
Indoor DB Indoor WB Capacity Outdoor DB, ° C
° C ° C kW 19.4 25 30 35 40 46 50 52 54
26.7
13.9 TC 6.736 6.413 6.125 5.837 5.657 5.369 5.231 5.178 5.136
SC 6.736 6.413 6.125 5.837 5.657 5.369 5.231 5.178 5.136
15 TC 7.385 6.936 6.535 6.135 5.946 5.644 5.499 5.443 5.399
SC 6.678 6.335 6.028 5.721 5.545 5.263 5.128 5.076 5.035
18 TC 9.153 8.362 7.655 6.948 6.734 6.391 6.227 6.164 6.114
SC 6.520 6.120 5.763 5.405 5.239 4.973 4.845 4.796 4.757
19.4 TC 9.979 9.027 8.177 7.327 7.101 6.740 6.567 6.501 6.448
SC 6.446 6.020 5.639 5.258 5.096 4.837 4.713 4.665 4.627
20 TC 10.333 9.353 8.478 7.604 7.369 6.995 6.815 6.746 6.691
SC 6.415 5.971 5.575 5.179 5.019 4.764 4.642 4.595 4.558
22 TC 11.512 10.440 9.482 8.525 8.262 7.842 7.641 7.564 7.502
SC 6.309 5.809 5.362 4.915 4.763 4.521 4.405 4.360 4.325
24 TC 12.691 11.526 10.486 9.446 9.155 8.690 8.467 8.381 8.313
SC 6.204 5.646 5.148 4.650 4.507 4.278 4.168 4.126 4.092
HIGH AMBIENT
Model : MCK030A / MLC030C
Indoor DB Indoor WB Capacity Outdoor DB, ° C
° C ° C kW 19.4 25 30 35 40 46 50 52 54
26.7
13.9 TC 8.487 8.015 7.593 7.171 6.827 6.468 6.189 6.037 5.877
SC 8.487 8.015 7.593 7.171 6.827 6.468 6.189 6.037 5.877
15 TC 9.047 8.490 7.993 7.495 7.136 6.761 6.469 6.310 6.143
SC 8.036 7.632 7.272 6.912 6.581 6.235 5.965 5.819 5.665
18 TC 10.574 9.786 9.083 8.380 7.978 7.559 7.232 7.055 6.868
SC 6.805 6.590 6.398 6.206 5.908 5.598 5.356 5.225 5.086
19.4 TC 11.286 10.391 9.592 8.792 8.371 7.931 7.588 7.402 7.206
SC 6.230 6.103 5.990 5.876 5.595 5.301 5.072 4.947 4.816
20 TC 11.592 10.675 9.856 9.038 8.604 8.152 7.800 7.609 7.407
SC 5.984 5.863 5.756 5.648 5.377 5.095 4.875 4.755 4.629
22 TC 12.610 11.621 10.738 9.856 9.383 8.890 8.506 8.297 8.078
SC 5.163 5.064 4.975 4.887 4.652 4.408 4.217 4.114 4.005
24 TC 13.627 12.567 11.620 10.673 10.161 9.627 9.212 8.986 8.748
SC 4.342 4.264 4.195 4.125 3.927 3.721 3.560 3.473 3.381
HIGH AMBIENT
26
