Instrument cluster
31
Function Page
1
Coolant temperature gauge 125
D Coolant temperature
warning lamp
303
2
Speedometer with:
L Left turn signal indi-
cator lamp
v ABS/ESP
®
warning
lamp
296
E Distronic indicator
lamp (white) or distance
warning lamp (red)
1
149,
150
; Brake warning lamp,
USA only
295
3 Brake warning lamp,
Canada only
295
K Right turn signal indi-
cator lamp
Function Page
3
Left multifunction dis-
play with:
Outside temperature indi-
cator or digital speedome-
ter (depending on selected
setting in the control sys-
tem)
129,
136
Main odometer 127
Set speed for cruise control
or Distronic
144,
150
4
Reset button for:
Resetting trip odometer 125
Resetting individual set-
tings 135
Adjusting instrument clus-
ter illumination 125
1
Vehicles without Distronic: Warning/indicator lamp without function. It illuminates when the ignition is switched on. It should go out when the engine is running.
At a glance
