Seats
Adjusting the front seat mechanically (with
Seat Comfort Package)
#
To adjust the seat cushion length: lift lever
1 and slide the front section of the seat
cushion forwards or backwards.
#
To adjust the seat fore-and-aft position:
lift lever 2 and slide the seat into the
desired position.
#
Make sure that the seat is engaged.
#
To adjust the seat cushion inclination:
turn handwheel 3 forwards and backwards
until the desired position has been reached.
#
To adjust the seat height: push or pull lever
4 until the desired position has been
reached.
#
To adjust the seat backrest inclination:
turn handwheel 5 forwards and backwards
until the desired position has been reached.
Adjusting the front seat electrically
1
Seat backrest inclination
2
Seat height
3
Seat cushion inclination
4
Seat fore-and-aft position
#
Save the settings with the memory function
(/ page 97).
90
Seats and stowing
