398
Practical hints
Replacing bulbs
Halogen headlamp
왘 Press the tab on cover 3 and remove
cover.
왘 Pull connector 7 off of the lamp.
왘 Release the retaining springs and take
out the bulb.
왘 Insert the new bulb in the socket so
that the base is in the recess on the
lower left.
왘 Attach the retaining springs.
왘 Insert connector 7 into the bulb.
왘 Press cover 3 onto the housing until
the tab engages.
Replacing halogen high beam bulbs
왘 Press the tab on cover 2 and remove
cover.
왘 Pull connector 6 off of the bulb.
왘 Apply pressure on the bulb contacts
from above until the bulb releases from
the retaining springs.
왘 Remove bulb.
왘 Insert the new bulb in the socket with
the marking facing upward.
왘 Press the bulb upward on the contacts
until it engages in the retaining springs.
왘 Insert connector 6 onto the bulb.
왘 Press cover 2 onto the housing until
the tab engages.
Front turn signal lamp bulb
왘 Turn bulb socket 8 counterclockwise
and pull out.
왘 Gently push bulb into socket, turn
counterclockwise and remove.
왘 Insert new bulb in socket, push in and
twist clockwise.
왘 Reinstall bulb socket in lamp and twist
clockwise until it engages.
