400
Practical hints
Replacing bulbs
Tail lamp unit
Passenger side
1 Black socket:
Backup lamp
2 Red socket:
Driver’s side: Tail, parking and rear fog
lamp
Passenger side: Tail and parking lamp
3 Red socket:
Tail, standing and parking lamp
4 White socket:
Turn signal lamp
왘 Driver’s side: Turn the locking knob and
move the trim to the side.
왘 Passenger side: Fold the trim to the
side.
왘 Turn bulb socket counterclockwise and
pull out.
왘 Gently twist bulb counterclockwise and
pull out of bulb holder.
왘 Insert new bulb into the holder and turn
it clockwise.
왘 Reinstall bulb socket.
The bulb socket should audibly click.
왘 Driver’s side: Replace the trim and se-
cure with lock.
왘 Passenger side: Reinstall the trim.
License plate lamp
1 Screws
왘 Loosen both screws 1.
왘 Remove the license plate lamp.
왘 Replace the bulb.
왘 Reinstall the license plate lamp.
왘 Retighten screws 1.
