Mercury 300R HD CMS Mechanical User Manual

Exhaust Water Strainer Inspection
IMPORTANT: The water strainer is an integral component of the cooling
system. It should be inspected every 100 hours of operation or once a year,
whichever occurs first.
1.
Remove the top cowl. Refer to Top Cowl Removal and Installation.
2. Remove the hose from the exhaust water spray inlet assembly. Press on
the hose lock and pull the hose off the assembly.
a - Exhaust water spray inlet assembly
b - Hose lock
3. Remove the strainer from the assembly.
64630
Strainer
a
b
64629
MAINTENANCE
eng 77
