OUTBOARD INSTALLATION
100
NOTE: The inside holes on the transom reinforcement plate are
for the lower transom bolts and the outside holes are for the upper
transom bolts.
a
b
20860
a - Large transom washer
b - Transom reinforcement plate
Description Part Number
Large transom washer 67‑896392
Transom reinforcement plate 67‑896305
Fastening the Outboard
1. Drill four 13.5 mm (17/32 in.) mounting holes.
2. Install the outboard so that the water intake housing is set at
the correct height. Refer to Determining Outboard Mounting
Height.
3. Apply marine sealer to shanks of bolts. Do not apply marine
sealer to the threads of the bolts.
4. Fasten the outboard with provided mounting hardware shown.
Tighten locknuts to the specifed torque.
