FEATURES & CONTROLS
40
Remote Control Features
Your boat may be equipped with one of the Mercury Precision or
Quicksilver remote controls shown. If not, consult your dealer for
a description of the functions and operations of the remote control.
f
a
c
d
e
b
h
c
a
g
d
e
b
i
f
g
i
c
a
f
26800
a - Control handle ‑ forward, neutral, reverse
b - Neutral release lever
c - Lanyard stop switch ‑ Refer to General Information ‑
Lanyard Stop Switch
d - Trim/tilt switch (if equipped) ‑ Refer to Features and
Controls ‑ Power Trim and Tilt
e - Lanyard ‑ Refer to General Information ‑ Lanyard Stop
Switch
f - Throttle friction adjustment ‑ Console controls require
cover removal for adjustment
g - Ignition key switch ‑ "OFF," "ON," START"
h - Fast idle lever ‑ Refer to Operation ‑ Starting the Engine
i - Throttle only button ‑ Refer to Operation ‑ Starting the
Engine
