Mercury 45 User Manual

INSTALLATION
20
Installing Outboard
!
WARNING
Before operation, the outboard must be correctly installed with the required mounting hardware as shown.
Failure to correctly fasten outboard could result in outboard ejecting off boat transom causing serious injury,
death, or property damage.
We strongly recommend that your dealer install your outboard and related accessories to ensure proper installation
and good performance. If you install the outboard yourself, follow instructions in the outboard installation manual
which is provided with the outboard.
MODELS WITHOUT TRANSOM BRACKET CLAMP SCREWS
The outboard must be secured to the transom with the four 12.7 mm (1/2 in.) diameter mounting bolts and locknuts
provided. Install two bolts through the upper set of holes and two bolts through the lower set of holes.
3068
MODELS WITH TRANSOM BRACKET CLAMP SCREWS
The outboard must be secured to the transom one of two ways: either with clamp screws and the two mounting
bolts, washers and locknuts provided, or with clamp screws and optional Quicksilver or Mercury Precision Parts
Outboard Mounting Kit.
3069
a
b
c
d
a
a - Transom bracket clamp screws
b - Mounting bolts, washers and locknuts
c - Outboard mounting kit
d - Retainer screw
