a - Special washer head bolt (10-856680)
b - Nylon insert locknut (11-826709113)
c - Spacer
d - Flat washers
e - Nylon insert locknut (11-826709113)
Description Nm lb. in. lb. ft.
Special washer head bolt 27 20
Nylon insert locknut "b" 27 20
Nylon insert locknut "e" Tighten until seats, then back off 1/4 turn
Fuse Replacement - Electric Start Models
IMPORTANT: Always carry spare SFE 20 AMP fuses.
The electric starting circuit is protected from overload by an SFE 20 AMP fuse. If the fuse is blown, the electric
starter motor will not operate. Try to locate and correct the cause of the overload. If the cause is not found, the
fuse may blow again.
1. Open the fuse holder and look at the silver colored band inside the fuse. If band is broken, replace the fuse.
Replace fuse with a new fuse with the same rating.
