One anode is installed on the bottom of the transom bracket assembly. The
trim tab is also an anode on the 87.3 mm (3‑7/16 in.) diameter gearcase. The
108 mm (4‑1/4 in.) diameter gearcase has three anodes. One of the anodes is
the trim tab, and the other two anodes are located on each side of the
gearcase.
a - Transom bracket anode
b - Trim tab
c - Anode on each side of gearcase
Propeller Replacement–Standard Gearcase
!
WARNING
Rotating propellers can cause serious injury or death. Never operate the boat
out of the water with a propeller installed. Before installing or removing a
propeller, place the drive unit in neutral and engage the lanyard stop switch
to prevent the engine from starting. Place a block of wood between the
propeller blade and the anti‑ventilation plate.
1. Shift outboard to neutral (N) position.
N
26838
N
29176
3124
c
b
a
MAINTENANCE
58 eng
