Mercury PI865GVM7 Series User Manual

5
Chapter 2: Motherboard Installation
Chapter 2 Motherboard Installation
To install this motherboard in a system, please follow these instructions in this
chapter:
 Identify the motherboard components
 Install a CPU
 Install one or more system memory modules
 Make sure all jumpers and switches are set correctly
 Install this motherboard in a system chassis (case)
 Connect any extension brackets or cables to headers/connectors on the
motherboard
 Install peripheral devices and make the appropriate connections to
headers/connectors on the motherboard
Note:
1 Before installing this motherboard, make sure jumper JP1 is under
Normal setting. See this chapter for information about locating JP1 and
the setting options.
2 Never connect power to the system during installation; otherwise, it
may damage the motherboard.

Mercury PI865GVM7 Series Specifications

General

Form Factor	Micro ATX
Chipset	Intel 865GV
Socket Type	Socket 478
Memory Slots	2 x DIMM
Maximum Memory	2 GB
Integrated Graphics	Intel Extreme Graphics 2
Expansion Slots	1 x AGP 8X, 3 x PCI
Memory Type	DDR
Audio	Realtek ALC655 6-channel
LAN	10/100 Mbps
Storage Interfaces	2 x ATA100, 2 x SATA 1.5Gb/s
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
