Mercury VesselView 702 User Manual

Section 2 - Initial Screens and Setup Wizard
90-8M0109374 eng JUNE 2016 Page 43
Speed Setup
In the Speed Setup menus, there are three options for determining how VesselView will acquire speed information. If the vessel
is equipped with a GPS, the drop‑down menu will allow selection of available devices. If the vessel is equipped with a pitot
sensor, this option will be selected. If the vessel is equipped with a paddle wheel, then an option to select will drop‑down. After
the speed source has been selected, select Next to continue.
61529
The pitot and paddle wheel source selection is shown in the following illustration. Select the engine or drive unit that transmits
the speed data to the VesselView.
a - PCM0 = starboard outer
b - PCM1 = port outer
c - PCM2 = starboard inner or center
d - PCM3 = port inner
a
a
a
b
b
b
c
c
d
60056
a
