Complementary power MOSFET output stages class AB/H
1240 Watts (620 Watts per channel)
< .02 %
Acoustical
1
±4 dB 50 – 160 Hz
±60° 60 – 200 Hz
140 peak
136 dB continuous; 140 peak ¿¿check
> 120 dB
120° H x 120° V
Specifications
Frequency Response
2
Phase Response
2
Maximum SPL
Music as source
Pink noise as source
Dynamic Range
3
Coverage
Transducers
Low Frequency
Audio Input
Type
Connector
Nominal Input Level
Amplifiers
Type
Burst Capability
4
THD, IM, TIM
AC Power
Connector
Automatic voltage selection
5
Max Continuous RMS Current (> 10s)
Max Burst RMS Current (< 1s)
Max Peak Current During Burst
Soft-Current Turn-on
Physical
Dimensions
Weight
Enclosure/Finish
Protective Grill
Rigging
10 kΩ impedance, electronically balanced
XLR (A-3) male and female
+4 dBu (1.23 Vrms)
Two 15" diameter MS-15 cone
250 V NEMA L6-20P / IEC 309 Twistlock male receptacle
85 – 134 V / 165 – 264 V; 50 Hz / 60 Hz
115 V: 8 A 230 V: 4 A 100 V: 10 A
115 V: 15 A 230 V: 8 A 100 V: 18 A
115 V: 22 Apk 230 V: 11 Apk 100 V: 25 Apk
Inrush current < 12A @115V
21.25” W x 56.75” H x 30” D
221 lb (100 kg); shipping: 267 lb (121 kg)
Multi-ply hardwood/black textured
Perforated steel grill, grey foam
Six aircraft pan fittings (three on top and bottom).
Working load for each fitting is 600 lb, based on a
5:1 safety factor, with a straight tensile pull.
Notes
1. Acoustical specifications are for the minimum
configuration of two DS-2P cabinets and are
measured at 2 m on-axis from the 1/R image
(located at the rear of the cabinet).
2. Subject to half-space loading; measured
with one-third octave frequency resolution in
fixed ISO bands.
3. Measured as the ratio between the peak SPL
and the A-weighted noise floor.
4. Nominal 8
Ω
resistive load, pink noise, 100 V
peak.
5. The unit is rated at 88–125 V and 182–235 V,
50/60 Hz, to satisfy EC standards for –10% to
6% AC line voltage.
