MCAC-VTSM-2017-01 Compact Four-way Cassette
44
2. Specifications
Model
MDV-D15Q4/N1-A3
MDV-D22Q4/N1-A3
MDV-D28Q4/N1-A3
Power supply
1 phase, 220-240V, 50Hz
Cooling
Capacity
kW
1.5
2.2
2.8
Input
W
36
50
50
Rated current
A
0.22
0.22
0.22
Heating
Capacity
kW
1.7
2.4
3.2
Input
W
36
50
50
Rated current
A
0.22
0.22
0.22
Indoor fan motor
Model
YDK15-6M
Type
AC
Input
W
33
34
34
Capacitor
uF
1
1.2
1.2
Speed (H/M/L)
r/min
630/540/447
658/586/485
658/586/485
Indoor coil
Number of rows
1
Tube pitch(a) × row pitch(b)
mm
21×13.37
Fin spacing
mm
1.3
Fin type
Hydrophilic aluminium
Tube outside dia. and type
mm
Ф7
Inner groove tube
Coil length × height × width
mm
1310×210×13.37
Number of circuits
1
2
2
Indoor air flow (H/M/L)
m
3
/h
435/283/208
414/313/238
414/313/238
Sound pressure level (H/M/L)
dB(A)
35/33/23
36/33/23
36/33/23
Indoor unit
Dimension (W×H×D)
mm
570×260×570
Packing (W×H×D)
mm
675×285×675
Net/Gross weight
kg
16/19.5
16/20
16/20
Panel
Dimension (W×H×D)
mm
647×50×647
Packing (W×H×D)
mm
715×123×715
Net/Gross weight
kg
2.5/4.5
Refrigerant Type
R410A
Throttle
Type
Electronic expansion valve
Design pressure(H/L)
MPa
4.4/2.6
Pipe connections
Liquid pipe
mm
Ф6.35
Gas pipe
mm
Ф12.7
Drain pipe
mm
ODФ25
Controller
Wireless remote controller
Notes:
1. Nominal cooling capacities are based on the following conditions: return air temperature: 27°CDB, 19°CWB, and outdoor
temperature:35°CDB, equivalent ref. piping: 7.5m (horizontal)
2. Nominal heating capacities are based on the following conditions: return air temperature: 20°CDB, outdoor temperature:
7°CDB, 6°CWB, and equivalent ref. Piping: 7.5m (horizontal)
3. 1.5kW model is only available for V4 Plus system, MINI VRF system and V4+I(side discharge) system.
