MCAC-VTSM-2017-01 Compact Four-way Cassette
46
3. Dimensions
523(Hook-location)
570(Body)
647(Panel)
Drain side
(Unit: mm)
545(Hook-location)
570(Body)
647(Panel)
A
60
Ceiling
Panel
Hook
A
072
Nut
Body
600
50
