Midea MDV-D112Q4/N1-D User Manual

One-way Cassette MCAC-VTSM-2017-01
3
2. Specifications
Model
MDV-D18Q1/N1-D
MDV-D22Q1/N1-D
Power supply
1 phase, 220-240V, 50Hz
Cooling
Capacity
kW
1.8
2.2
Input
W
41
41
Rated current
A
0.24
0.24
Heating
Capacity
kW
2.2
2.6
Input
W
41
41
Rated current
A
0.24
0.24
Indoor fan motor
Model
RPS12N
Type
AC
Input(H/M/L)
W
29.5/26.7/25.0
29.5/26.7/25.0
Capacitor
μF
0.8
Speed (H/M/L)
r/min
1180/955/710
Indoor coil
Number of rows
2
Tube pitch(a) × row pitch(b)
mm
21×13.37
Fin spacing
mm
1.5
Fin type
Hydrophilic aluminum
Tube outside dia. and type
mm
Ф7 Inner groove tube
Coil length × height × width
mm
760×252.4×26.74
Number of circuits
2
Indoor air flow (H/M/L)
m
3
/h
523/404/275
Sound pressure level (H/M/L)
dB(A)
37/34/30
38/34/30
Indoor unit
Dimension (W×H×D)
mm
1054×153×425
Packing (W×H×D)
mm
1155×245×490
Net/Gross weight
kg
12.5/16
Panel
Dimension (W×H×D)
mm
1180×25×465
Packing (W×H×D)
mm
1232×107×517
Net/Gross weight
kg
3.5/5.2
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Design pressure(H/L)
MPa
4.4/2.6
Pipe connections
Liquid pipe
mm
Ф6.35
Gas pipe
mm
Ф12.7
Drain pipe
mm
OD Ф25
Standard Controller
Wireless remote controller
Notes: 1. Nominal cooling capacities are based on the following conditions: return air temperature : 27°CDB,19°CWB,
outdoor temperature:35°CDB,equivalent refrigerant piping: 7.5m(horizontal).
2. Nominal heating capacities are based on the following conditions: return air temperature: 20°CDB,
outdoor temperature: 7°CDB,6°CWB,equivalent refrigerant piping: 7.5m(horizontal)
