Midea MFA-12HRN1 User Manual

Specifications MCAC-UTSM-2009-03
18 Outdoor Units
1. Specifications
Model MON-12HN1 MON-18HN1 MON-12HN1-Q
Code 220075100200 220075200460 220075100210
Power supply V-ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Max. input consumption W 1500 2000 1500
Max. input current A 7.5 12 7.5
Starting current A 29.9 31.8 29.9
Compressor
Model PA140X2C-4FT PA200X2CS-4KU1 PA140X2C-4FT
Type Rotary Rotary Rotary
Brand Midea-TOSHIBA Midea-TOSHIBA Midea-TOSHIBA
Supplier Midea-TOSHIBA Midea-TOSHIBA Midea-TOSHIBA
Capacity Btu/h 11566.68 16787.04 11566.68
Input W 1150 1670 1150
Rated current (RLA) A 5.3 7.81 5.3
Locked rotor Amp (LRA) A 29.9 31.8 29.9
Thermal protector Internal Internal Internal
Capacitor μF 35μF/440-450V 50μF/440-450V 35μF/440-450V
Refrigerant oil ml
ESTEL OIL VG74,
480
ESTER OIL VG74,
750
ESTEL OIL VG74,
480
Outdoor fan
motor
Model YDK24-6F YDK53-6K YDK24-6F
Type AC MOTOR AC MOTOR AC MOTOR
Brand WELLING WELLING WELLING
Input W 58 130 58
Capacitor μF 2.5μF/450V 2.5μF/450V 2.5μF/450V
Speed r/min 800 750 800
Outdoor coil
Number of rows 2 2 2
Tube pitch(a) × row
pitch(b)
mm 21×13.37 22×19.05 21×13.37
Fin spacing mm 1.5 1.6 1.5
Fin type
Hydrophilic
aluminum
Hydrophilic
aluminum
Hydrophilic
aluminum
Tube outside dia. and type mm
Ф7 Inner grooved
copper tube
Ф7.94 Inner grooved
copper tube
Ф7 Inner grooved
copper tube
Coil length × height × width mm 628×504×26.74 630×660×38.1 628×504×26.74
Number of circuits 2 2 2
Outdoor air flow m
3
/h 1985 2770 1985
Outdoor noise level (sound pressure) dB(A) 52.8 55.5 52.6
Outdoor unit
Dimension(W×H×D) mm 780×547×250 842×695×324 780×547×250
Packing (W×H×D) mm 910×575×335 975×770×405 910×575×335
Net/Gross weight kg 34/38 52/56 35/39
Refrigerant
Type R410A R410A R410A
Charged volume g 1120 1300 1120
Design pressure MPa 4.2/2.0 4.2/2.0 4.2/2.0
Refrigerant
piping
Liquid side/ Gas side mm φ6.4/φ12.7 φ6.4/φ12.7 φ6.4/φ12.7
Max. pipe length m 15 20 —
Max. difference in level m 5 10 —
Ambient temp. ℃
cooling: 21~43;
heating: -5~24
cooling: 21~43;
heating: -5~24
cooling: 21~43;
heating: -5~24
