Specifications MCAC-UTSM-2009-03
6 Indoor Units
1. Specifications
Model MFA-12HRN1 MFA-18HRN1 MFA-12HRN1-Q
Code 220044000090 220044100280 220044000100
Power supply V-ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Cooling
Capacity Btu/h 12000 18000 12000
Input W 1096 1650 1101
Heating
Capacity Btu/h 13380 19600 13300
Input W 1122 1715 1117
Indoor fan
motor
Model RD-280-20-8A RD-280-20-8A RD-280-20-8A
Type DC MOTOR DC MOTOR DC MOTOR
Input W 24.5/19.5/16.8/13/10.5 38/33.5/24.5/15.2 24.5/19.5/16.8/13/10.5
Capacitor uF / / /
Speed(Hi/Mi/Lo) r/min 680/610/560/460/420 890/840/780/680/530 680/610/560/460/420
Indoor coil
Number of rows 2 2 2
Tube pitch(a)×row
pitch(b)
mm 21×13.37 21×13.37 21×13.37
Fin spacing mm 1.3 1.3 1.3
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia. and
type
mm
Ф7 Inner grooved
copper tube
Ф7 Inner grooved
copper tube
Ф7 Inner grooved
copper tube
Coil length× height ×
width
mm 512×378×26.74 512×378×26.74 512×378×26.74
Number of circuits 2 2 2
Indoor air flow(Hi/Mi/Lo) m
3
/h 550/490/460/380/350 740/700/640/560/440 550/490/460/380/350
Indoor noise level (sound pressure) dB(A) 35/33/31/27/23 38/35/33/31/29 35/33/31/27/23
Indoor unit
Dimension (W×H×D) mm 700×600×210 700×600×210 700×600×210
Packing (W×H×D) mm 810×710×305 810×710×305 810×710×365
Net/Gross weight kg 15/20 15/20 20/25
Refrigerant type R410A R410A R410A
Design pressure MPa 4.2/2.0 4.2/2.0 4.2/2.0
Refrigerant
piping
Liquid side/ Gas side mm φ6.4/φ12.7 φ6.4/φ12.7 φ6.4/φ12.7
Drainage water pipe diameter mm φ16 φ16 φ16
Connection
wiring
Power wiring mm
2
3×1.5 3×2.5 3×1.5
Signal wiring mm
2
4×1.5 4×2.5 4×1.5
Controller R51D/E(standard) R51D/E(standard) R51D/E(standard)
Operation temperature ℃ 17~30 17~30 17~30
