Part name: 1 – Inlet valve block
6. Reverse the above procedure to install. And check out all connectors connects well.
Part name: 1 – floater holder 2 – microswitch (floater assembly) 3 – floater
Removal and Installation
1. Take off cutlery basket, basket and filter system.
2. Remove shell. (see shell removal and installation)
3. Take out two corner boards, absorber sound, backboard, hollow plate.
4. Remove tank assembly. (see tank assembly removal and installation)
5. Take up the bottom board; remove two screws for fixing floater assembly.
6. Pull out all locking terminals for connecting Microswitch (floater assembly).
7. Reverse the above procedure to install. And check out all connectors connects well.
Removal and Replacement
1. Remove floater assembly. (see floater assembly
removal and installation)
2. Pull out all locking terminals for connecting
Microswitch (floater assembly).
3. Remove one screw for fixing Microswitch (floater assembly).
4. Replace a new Microswitch (floater assembly)
5. Reverse the above procedure to install. And check out all connectors connects well.
Water softener is an instrument for softening hard water in some location.
Water softener
Microswitch (floater assembly)
Floater assembly
1
Clam
Lockin
terminals
1
2
3
Screws
