Part Name: 1 – Nut of air breather 2 – Nut of siphon 3 – Cover of softener
4 – Sprayer 5 – Filter System
BackView
Part Name: 1 – Backboard 2 – Hollow plate 3 – Bottom board 4 – Power cord
Note: Throughout this manual, features and appearance may vary from your model.
WARNING: Always turn off the electric power supply before servicing any electrical component,
making ohmmeter checks, or replacing any parts.
Note: All voltage checks should be made with a voltmeter having a full scale range of 250 volts
or higher. After service is completed, be sure all safety grounding circuits are complete,
all electrical connections are secure, and all access panels are in place.
Dishwasher Components
1
2
3
4
5
1
2
3
4
Drain Hose
connecte
Inlet Hose
Connecter
