Activating Con@ctivity 2.0
48
Installation of the Con@ctivity
2.0 stick
In order for you to be able to use the
Con@ctivity 2.0 function, the cooktop
must be equipped with a Con@ctivity
2.0 stick.
See the relevant installation
instructions of the Con@ctivity 2.0
stick.
Activating the Con@ctivity 2.0
function
To use the Con@ctivity 2.0 function, the
radio link between the cooktop and the
ventilation hood must be activated.
Both appliances must be installed and
operational.
Wireless connection must be activated
on the ventilation hood and the cooktop
at the same time. Activation on the
ventilation hood is described below.
Activation on the cooktop is described
in the relevant operating and installation
instructions. Please refer to the
operating instructions before starting.
Activate the ventilation hood first, then
the cooktop.
Activating the ventilation hood
Signing on/off is carried out with the
canopy retracted.
Remove the grease filters.
The controls are accessible via the slots
for the grease filters.
The cooktop and ventilation hood
must be turned off.
Press and hold the delayed shut
down button 515 for approx. 10
seconds until the 1 indicator appears
in the fan level display.
Then, press the following buttons in
order:
– The button
– Followed by the button
– And then the lighting button .
If the remote control is already
activated, 2 and 3 will light up
constantly. If there is no wireless
connection 2 and 3 will flash at the
same time.
To activate Con@ctivity 2.0, press the
"" button.
The search for a wireless connection
will start.
As this is happening, activate the
cooktop.
