Miele DAS 2620 User Manual

Cleaning and care
23
NoSmell active charcoal filters
With recirculation mode, 2 charcoal
filters must be inserted in addition to
the grease filter. These are designed to
absorb cooking odours.
The charcoal filters are fitted in the
canopy above the grease filter.
Charcoal filters are available to order via
the Miele online shop (see end of this
booklet for contact details) or directly
from Miele.
The charcoal filters are listed under
“Technical data” at the back of this
booklet.
Fitting/Replacing the charcoal filters
The matching frames must be installed
in order to use the charcoal filters.
Follow the directions on the
installation sheet.
 Remove the grease filter from the
rangehood.
 Remove the charcoal filter packaging.
 Push the charcoal filters into the
frames until they engage firmly.
 Refit the grease filter.
 To remove the charcoal filters, press
the tab forwards slightly and pull the
filters down to remove them.

Miele DAS 2620 Specifications

General

Noise level	61 dB
Pressure (Pa)	422
Intensive speed	Yes
Number of speeds	3
Type of extraction	Ducted/Recirculating
Noise level (low speed)	47 dB
Maximum extraction power	559 m³/h
Noise level (medium speed)	55 dB
Maximum recirculating power	550 m³/h
Minimum distance from gas hob	650 mm
Noise level (intensive speed)	68 dB
Fluid dynamic efficiency class	A
Minimum distance from electric hob	450 mm
Current	10 A
Connected load	200 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	41.7 kWh
Bulb type	LED
Bulb power	3.2 W
Illuminance	310 lx
Number of bulbs	1 bulb(s)
Type	Built-in
Cord length	1.5 m
Control type	Buttons
Product color	Stainless steel
Built-in display	No
Exhaust location	Top
Exhaust connection diameter	150 mm
Number of filters	1 pc(s)

Weight and Dimensions

Width	596 mm
Weight	12000 g
Depth (max)	423 mm
Depth (min)	273 mm
Height (max)	436 mm
