Installation in a base unit
* Appliances with glass front
** Appliances with metal front
a Steam oven
b Building-in recess
c Inlet for mains connection cable to the appliance
d Recommended position for electrical socket.
Important: Do not position behind the appliance!
e Mains connection cable
N.B. Undercounter installation is not recommended if there are young children in
the home.
Appliance and building-in dimensions
53
600
500
560-568
455,5
460-465
446
549
595
444
75
70
c
b
d
e
a
0
22*/23**
