Installation in a tall unit in combination with an oven
* Appliances with glass front
** Appliances with metal front
a Steam oven
b Building-in recess
c Inlet for mains connection cable to the appliance
d Recommended position for electrical socket.
Important: Do not position behind the appliance!
e Mains connection cable
f Ventilation cut-out for installation with a pyrolytic oven
g Oven
Appliance and building-in dimensions
54
22*/23**
455,5
593-595
446
595
595
555
560-568
448-452
a
g
e
549
444
75
560-568
70
500
c
d
b
0
0
30
22*/23**
f
