3. Fitting the facia panel
The facia panel is delivered separately in the colour ordered with the necessary
accessories. It has to be fitted to the dishwasher when it is being installed.
Put the large cap b on the button for
the ON/OFF control switch.
Put the two small caps which have
one straight side
c on to the "+" and
"–" button switches. The straight
sides must face each other.
Put the 12 small oval caps d on to
all the other button switches
Place the seal supplied e in the
groove round the ventilation grille
f.
Push the ventilation grille f into posi-
tion.
Place the facia panel g in position
and screw into place from the inside
using the six screws
h.
For Information:
If the machine is equipped with the Info-
Control unit:
– first fit the transmitter
– then fit the facia panel.
Fitting instructions are supplied with the
transmitter.
Installing integrated “i” Dishwashers
66
