Installation work and repairs should
only be performed by a qualified
technician in accordance with all
applicable codes and standards.
Repairs and other work by
unqualified persons could be
dangerous and the manufacturer will
not be held responsible.
Before connecting the appliance to
the power supply make sure that the
voltage and frequency listed on the
data plate correspond with the
household electrical supply. This
data must correspond to prevent
machine damage. Consult a
qualified electrician if in doubt.
CAUTION: Before servicing,
disconnect the power supply by
either removing the fuse, unplugging
the unit or manually "tripping" the
circuit breaker.
Installer:
Please leave these instructions with
the consumer.
Power supply
The oven is equipped with a 6 ft./1.8 m
flexible power cord consisting of 4
wires ready for connection to a
dedicated 3 pole, 4 wire grounding
power supply:
–
120/240 V, 60 Hz, 20 A
or
–
120/208 V, 60 Hz, 20 A
Black wire: connect to L1 (hot), 20 A
Red wire: connect to L2 (hot), 20 A
White wire: connect to N (neutral)
Green wire: connect to GND (ground)
A dedicated line and junction box
should be used to connect the oven to
a 20 A circuit.
Connection details are also given on
the diagram located on the top of the
oven.
Electrical connection
61
