Anti-tipping mechanism
The anti-tipping mechanism a
ensures the housing unit b is securely
fixed to the wall and tipping of the
appliance is prevented.
,
Danger of tipping
The housing unit must be fixed to
the wall behind with several screws.
Only this can ensure that the
appliance will not tip over after
being installed.
Use two anti-tipping mechanisms for
each appliance or four for each
side-by-side combination of
appliances.
^
Position the anti-tipping mechanisms
a at the rear of the housing unit on
the left and right, leaving a gap to the
wall of no more than 10 mm.
^
While holding the anti-tipping
mechanisms in place, mark the
necessary drill holes at the top and
rear of the housing unit.
^ Put the anti-tipping mechanisms in a
safe place - they will be required
later.
Fixing screws for different uses and
types of material are supplied in the
accompanying pack.
If these are not suitable for the
anti-tipping mechanism in your
installation, you will need to secure it
by alternative means.
^
Secure the housing unit to the wall.
Installation
81

Miele KF 1801 Vi Specifications

General

Child lock	-
Door hinge	Right
Control type	Sensor
Product color	Stainless steel
Reversible doors	Yes
Shelves material	Tempered glass
Door opening angle	115 °
Appliance placement	Built-in
Door panel included	No
Noise level	40 dB
Climate class	SN-T
Total net capacity	390 L
Total gross capacity	- L
Form factor	Upright
Fridge number of compressors	2
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	15 kg/24h
Freezer net capacity	80 L
Storage time during power failure	15 h
Fridge net capacity	253 L
Fridge number of shelves/baskets	4
Fresh zone compartment net capacity	57 L
Connected load	- W
Annual energy consumption	373 kWh

Weight and Dimensions

Depth	610 mm
Width	750 mm
Height	2127 mm
