Miele KF 1801 Vi User Manual

Securing and aligning the
furniture door
^ Insert the angle trim m as far as it will
go into the spaces in the frame, as
shown.
^
Open the appliance door and hang
the furniture front on its frame onto
the threaded bolts, as shown n.
^
Press the pieces of angle trim m on
both sides into the white plastic
frame, and screw them down
securely. Spare screws can be found
in the plastic bag marked "E".
^
Screw the nuts o loosely onto the
threaded bolts, but do not tighten yet.
^
Close the door and check the
distance between the door and
neighbouring furniture doors.
^
Align the height of the appliance door
by sliding it over the threaded bolts
n.
^
Align the depth of the refrigerator
door via the gaps in the angle trim m.
Then screw the angle trim into
position.
^
Now screw on the top nuts o. The
door is now fixed.
Repeat the steps from "Preparing
the furniture fronts" to fit the furniture
front to the freezer drawer.
The positioning of the freezer drawer
front must be aligned to that of the
refrigerator door front.
Installation
89

Miele KF 1801 Vi Specifications

General

Child lock	-
Door hinge	Right
Control type	Sensor
Product color	Stainless steel
Reversible doors	Yes
Shelves material	Tempered glass
Door opening angle	115 °
Appliance placement	Built-in
Door panel included	No
Noise level	40 dB
Climate class	SN-T
Total net capacity	390 L
Total gross capacity	- L
Form factor	Upright
Fridge number of compressors	2
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	15 kg/24h
Freezer net capacity	80 L
Storage time during power failure	15 h
Fridge net capacity	253 L
Fridge number of shelves/baskets	4
Fresh zone compartment net capacity	57 L
Connected load	- W
Annual energy consumption	373 kWh

Weight and Dimensions

Depth	610 mm
Width	750 mm
Height	2127 mm
