Miele KF 1801 Vi User Manual

Connect the water inlet hose to the
appliance (see "Mains water
connection").
Preparing the furniture fronts
To ensure the correct alignment of
the furniture fronts, it is vital to fix the
furniture door to the refrigerator
before fixing the drawer front to the
freezer.
^
Load the door shelves in the
appliance door.
^ Open the appliance door as far as it
will go.
^
Unscrew the installation aids l and
angle trim m from the door.
^
Put the angle trim m and screws in a
safe place - they will be required
later.
^
Remove the cover from the light
contact switch.
^
Close the appliance door.
^ Measure the gap X between the
adjusting bar and the upper edge of
the adjacent furniture front.
^ Remove the two nuts from the
appliance door, and place them in a
safe place - they will be required
later.
^ Place the furniture front on a firm
surface, with the external side facing
downwards (place on a blanket or
similar to avoid it becoming
scratched).
Installation
87

Miele KF 1801 Vi Specifications

General

Child lock	-
Door hinge	Right
Control type	Sensor
Product color	Stainless steel
Reversible doors	Yes
Shelves material	Tempered glass
Door opening angle	115 °
Appliance placement	Built-in
Door panel included	No
Noise level	40 dB
Climate class	SN-T
Total net capacity	390 L
Total gross capacity	- L
Form factor	Upright
Fridge number of compressors	2
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	15 kg/24h
Freezer net capacity	80 L
Storage time during power failure	15 h
Fridge net capacity	253 L
Fridge number of shelves/baskets	4
Fresh zone compartment net capacity	57 L
Connected load	- W
Annual energy consumption	373 kWh

Weight and Dimensions

Depth	610 mm
Width	750 mm
Height	2127 mm
