Miele KF 9757 iD User Manual

Do not separate the soft-close
mechanism from the ball joint. This
would damage the mechanism.
^
Stand the appliance doors up one by
one, and slacken the hinges at the
front (the hinges remain open).
^
Remove caps a from the top and
bottom of each door (if the caps are
not in place, they will have been
supplied separately with the
appliance).
^
Remove screws b from all of the
hinges, and refit each hinge in its
diagonally opposite corner.
Do not close up the hinges. Danger
of injury.
^
Use a powered screwdriver to secure
the hinges; screws b are
self-tapping.
^
Replace caps a in the vacant holes
on the opposite side.
To secure the soft-close mechanism
^
Place the two doors with the outer
side downwards on a stable surface.
^ Screw ball joints b of soft-close
mechanism c into the new fixing
hole.
^
Open out soft-close mechanism c,
and hook mounting a onto the hinge.
^
Hold the soft-close mechanism in this
position, and screw mounting a to
the hinge.
Changing the door hinging
52

Miele KF 9757 iD Specifications

General

Door hinge	Right
Product color	White
Reversible doors	Yes
Appliance placement	Built-in
Door panel included	No
Fridge number of compressors	1
Noise level	39 dB
Total net capacity	203 L
Total gross capacity	- L
Fridge number of shelves/baskets	5
Freezing capacity	10 kg/24h
Freezer net capacity	57 L
Freezer number of shelves/baskets	2
Storage time during power failure	20 h
Annual energy consumption	292 kWh

Weight and Dimensions

Depth	550 mm
Width	560 mm
Height	1772 mm
