Electrical connection
The electrical connection must only be carried out
by a suitably qualified electrician in accordance
with local and national safety regulations.
The machine must only be connected to the voltage
and frequency shown on the data plate.
If the appliance is hard wired, a multiple-pole separa
-
tor must be installed. Separators with a contact gap
of more than 1/8" (3 mm) are valid as separators.
These include circuit breakers, fuses and relays.
The plug connection or the separator must be acces
-
sible at all times.
Connection should be made in accordance with the
wiring diagram and the installation diagram to a suit
-
able isolator, with an on-off switch which is easily ac
-
cessible for servicing. The wiring and installation dia
-
grams are important for the correct electrical functio
-
ning of the machine.
When the dryer has been connected, check the rota
-
tion direction of the fan. It must turn clockwise. If it
turns counter clockwise, two phases must be ex-
changed at the terminal box.
If the machine is disconnected from the electricity
supply ensure adequate measures are taken to ensu-
re that it cannot be reconnected to the electricity sup-
ply until all work has been carried out.
Potential equalization
A potential equalization must be provided if the leak
current exceeds 10 mA.
See the enclosed wiring and installation diagrams.
Air inlet and exhaust connection
This tumble dryer must only be used when it is con
-
nected to a suitable ducting system. The installation
site must be adequately ventilated.
See the installation instructions supplied.
Steam connection
Steam connection must only be carried out by an aut
-
horised installer.
See the installation instructions supplied.
A steam valve and condensate trap are available to
order from the Miele Spare Parts Department.
,
After setting up and connecting the dryer, en
-
sure that all outer casing parts are correctly fitted
back into position.
Installation and connection
30
