Height 850 mm
Width 595 mm
Depth 725 mm
Depth with door open 1085 mm
Weight 114 kg
Max. load bearing in operation 3000 Newton
Capacity 6.5 kg dry laundry
Voltage See data plate
Connected load See data plate
Fuse rating See data plate
Emission sound pressure level
in accordance with
EN ISO 11204/11203
<70dBre20µPa
Minimum water flow pressure 100 kPa (1 bar)
Maximum water flow pressure 1000 kPa (10 bar)
Inlet hose length 1.55 m
Mains connection cable length 1.80 m
Max. delivery head (drain pump
version)
1.00 m
LEDs Class 1
Product safety standard EN 10472, EN 60335
Test certificates awarded See data plate
Technical data
63
