Installation and connection
71
Examples
– Drainage into a sink or floor gully
Use the hose holder to prevent the
dr
ain hose from becoming kinked.
P
ress the small catches on the left
and right of the hose holder with your
thumbs (black arrows) and ...
...
pull the hose holder forwards to re‐
move it (white arrows).*
I
f you want to drain the water off
into a sink or basin, you will need to
secure the hose carefully, e.g. by ty‐
ing it to a tap, to make sure it cannot
slip during use (see the drawing un‐
der "Installation and connection -
Front view").
Overflowing water can cause dam‐
age.
The non-return valve can be fitted in
the end of the hose.
* You can refit the hose holder at a
lat
er stage if you decide that you no
longer want to drain the condensed
water externally.
Direct connection to a sink drain out‐
let
Remove the foll
owing from the back
of the dryer at the top: Adapter 1 and
hose clip 3 behind it.
Co
nnect the drain hose as described
below.
