Installation
*INSTALLATION*
64
Changing the door hinging
You can change the door hinging on
this tumble dryer yourself.
For safety reasons, the tumble dryer
must be disconnected from the
electricity supply before changing
the door hinging.
You will need:
– a T20 and T30 Torx screwdriver
– a flat head screwdriver or pointed
pliers
– the lock catch cover supplied
– the door hinge cover supplied
– a soft surface (e.g. a tablecloth)
Changing the hinging over
1. Remove the door from the dryer
 Open the door.
 Use a T30 Torx screwdriver to
unscrew the two screws on the base
plate of the door hinge .
The door cannot fall off as it is held in
place by two pins.
 Hold the door securely and pull it
forwards: to remove the door you will
need to pull the base plate of the
hinge with its two pins out of the
dryer.
To avoid scratching the door, place it
outer side downwards on a soft
surface (e.g. a tablecloth).
2. Change over the door lock on the
dryer
 Use a T30 Torx screwdriver to
unscrew the two screws on the door
lock .
 Use the screwdriver to press the door
lock upwards.
The door lock will spring out of its
position and can then be removed.

Miele TWB 140 WP Specifications

General

Drum type	Honeycomb
Color name	Lotus white
Door hinge	Left
Door style	Opaque door
Cord length	2 m
Control type	Rotary, Touch
Loading type	Front-load
Drying system	Heat pump
Product color	White
Reversible doors	-
Appliance placement	Freestanding
Inverter technology	Yes
Cycle time	155 min
Noise level	66 dB
Drying class	A
Drum capacity	7 kg
Refrigerating medium	R290
Refrigerating medium weight	110 g
Current	13 A
Heat source	Electric
Connected load	1100 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.7 kWh
Energy efficiency scale	A+++ to D
Power consumption (off)	0.3 W
Annual energy consumption	208 kWh
Delay start (max)	24 h

Weight and Dimensions

Depth	643 mm
Width	596 mm
Height	850 mm
Weight	58000 g
Depth with door open	1077 mm
