Milton Roy MAXROY B User Manual

35
6.4 PARTS LIST FOR MROY ECC MOUNTING ADAPTER
Model: mRoy “A”
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QUANTITY REF
CODE
16 - Kit, ECC Retrofit, RT, RH, & RJ
Plunger, Includes Wrench
30268 1
- Kit, ECC Retrofit, RA & RP Plunger,
Includes Wrench
30280 1
140 Plug Assembly, Adapter 1” NPT 2430045020 1
140 Plug Assembly, Adapter 1/2” NPT 2430045000 1
150 O-Ring, Cont. Spool, Urethane 2-113 4080109082 3
160 Spool, Control 2680037006 1
170 Sleeve, Threaded - 316ss 2430058016 1
180 Screw, Socket Set, 06-32NC x 1/4 4050039035 1
190 Plate,% Capacity - Aluminum 2530015062 1
200 Ring, Calibration - Aluminum 2530024062 1
210 Knob, Capacity Adjustment 2550035077 1
213 Bearing, Control Spool 2370076052 1
217 Washer, Thrust - 5/16 Steel 4040147031 1
810 Coupling, Drive 2520138077 1
820 Lockwasher, Drive Coupling #6 Inter-
nal Tooth
4040104071 2
830 Screw, Drive Coupling Pan Head 6-
32 x 3/8
4050178033 2
840 Bracket, Mounting 2040149006 1
860 Nut, Serrated Flange 1/4-20NC 4050323036 1
880 Screw, Socket Head 5/16-18 x 5/8 4050157024 1
900 ECC See Table 2 1
910 Shaft, Drive 2680052077 1
910 Shaft Assembly, Drive: Includes
Items 910, 915, & 920
2680055000 1
915 Pin, Drive Shaft 1/8x1-1/8 4010021133 1
920 Pin, Drive Shaft Spring.187x5/8 4010005032 1
930 Lockwasher, Spring 3/8 4040041022 4
935 Bolt, Hex Head 3/8-16 x 3/4 Lg. 4050018096 4
950 Sideguard, Left 2490110006 1
960 Sideguard, Right 2490109006 1
970 Screw, Button Head - 10-32 x 5/16 4050282087 4
1450 Label, Warning 2530097000 1
