Mindray BeneHeart D20 User Manual

A - 17
Nellcor SpO
2
Module
A.8.5 PR Specifications
PR from Mindray SpO
2
Module
PR from Masimo SpO
2
Module
Refreshing rate ≤1 s
SpO
2
averaging time 2-4 s, 4-6 s, 8 s, 10 s, 12 s, 14 s, 16 s
Low perfusion conditions Pulse amplitude: >0.02%
Light penetration: >5%
Low perfusion SpO
2
accuracy
2
±2%
PI measurement range 0.02 to 20%
1
The Masimo pulse oximeter with sensors have been validated for no motion accuracy in human blood studies on healthy
adult volunteers in induced hypoxia studies in the range of 70% to 100% SpO2 against a laboratory co-oximeter and ECG
monitor. This variation equals plus or minus one standard deviation. Plus or minus one standard deviation encompasses
68% of the population. One percent was added to the accuracies for neonatal sensors to account for accuracy variation due
to properties of fetal hemoglobin.
The Masimo pulse oximeter with sensors has been validated for motion accuracy in human blood studies on healthy adult
volunteers in induced hypoxia studies while performing rubbing and tapping motions at 2 to 4 Hz. At an amplitude of 1 to
2 cm and non-repetitive motion between 1 to 5 Hz. At an amplitude of 2 to 3 cm in induced hypoxia studies in the range of
70% to 100% SpO2 against a laboratory co-oximeter and ECG monitor. This variation equals plus or minus one standard
deviation. Plus or minus one standard deviation encompasses 68% of the population.
2
The Masimo pulse oximeter has been validated for low perfusion accuracy in bench top testing against a Biotek Index 2
simulator and Masimo's simulator with signal strengths of greater than 0.02% and a % transmission of greater than 5% for
saturations ranging from 70 to 100%. This variation equals plus or minus one standard deviation. Plus or minus one
standard deviation encompasses 68% of the population.
Standard Meet standards of ISO 80601-2-61
Measurement range 0 to 100%
Resolution 1%
Response time ≤30 s (normal perfusion, no disturbance, SpO
2
value sudden change from
70% to 100%)
Accuracy 70% to 100%:
70% to 100%:
0 to 69%:
±2%ABS (adult, pediatric)
±3%ABS (neonate)
not specified
Refreshing rate ≤1 s
When the SpO
2
sensor is applied for neonatal patients as indicated, the specified accuracy range is increased by ±1%, to
compensate for the theoretical effect on oximeter measurements of fetal hemoglobin in neonatal blood.
Measurement range 20 to 300 bpm
Resolution 1 bpm
Response time <30 s (normal perfusion, no disturbance, PR value sudden changes from 25
to 220bpm)
Accuracy ±3 bpm
Refreshing rate ≤1 s
Measurement range 25 to 240 bpm
Resolution 1 bpm
Response time ≤20 s (with normal perfusion, no disturbance, and a PR value transition from
25 to 220 bpm)

Mindray BeneHeart D20 Specifications

General

Model	BeneHeart D20
Connectivity	USB
Operating Temperature	0°C to 50°C
Energy Levels (Pediatric)	50J
Analysis Time	<10 seconds
Monitoring Parameters	ECG
NIBP Measurement	Not available
SpO2 Measurement	Yes
Temperature Measurement	Not available
Voice Prompts	Yes
CPR Guidance	Yes
Data Recording	Yes
Data Transfer	USB
Battery Type	Lithium-ion battery
Storage Temperature	-20°C to 60°C
