System Diagnosis and Support 9-1
9 System Diagnosis and
Support
9.1 General Status Indicator
9.1.1 The Status Indicators on the Control Panel
Status
indicators
Icon
Status definition and indicators
Position
Power-on
status
indicator
The indicator is not on when the system is
turned off;
Press the key, the indicator blinks green at
power on.
After power on, the indicator is green.
The Control
Panel
on the upper
right corner
Battery
status
indicator
1. It illuminates in orange when battery is
charging;
2. It illuminates in green when battery is
charging to100% electricity;
3. When the battery capacity is more than 20%
in discharging status, the indicator is green.
4. When the battery capacity is less than 20% in
discharging status, the orange indicator blinks;
When less than 10%, the orange indicator blinks
quickly.
5. When the battery is in
non-charging/discharging status or no battery is
in, the indicator is not on.
The Control
Panel
on the upper
right corner
AC
indicator
The indicator blinks on green when the system
is connected to the AC power supply. The
indicator is not on when battery supplied.
The Control
Panel
on the upper
right corner
Hard disk
indicator
The indicator light flashes in green when the
hard disk is reading or writing.
The indicator is off automatically in other
situations.
The Control
Panel
on the upper
right corner
