Mindray DP-9900Plus User Manual

Hardware Introduction
2-5
8
A+5 A+5 A+5
9
A+5 A+5 A+5
10
A+5 A+5 A+5
11
GND GND GND
12
HVC GND GND
13
GND GND GND
14
GND GND GND
15
2V5 2V5 2V5
16
GND GND GND
17
1V5 1V5 1V5
18
1V5 1V5 1V5
19
GND GND GND
20
GND GND GND
21
3V3 3V3 3V3
22
3V3 3V3 3V3
23
GND GND GND
24
GND GND GND
25
13V5 13V5 13V5
26
NC GND GND
27
NC GND NC
28
GND GND GND
29
NC GND NC
30
GND GND GND
31
D+5 D+5 D+5
32
D+5 D+5 D+5
2.2.3.2. Interfaces to Main Board
The interfaces between the connection board and the main board are defined in the table
below.
P2
A B C D E
1
HV HV HV HV HV
2
GND GND GND GND GND
3
FA-5 FA-5 FA-5 FA-5 FA-5
4
GND GND GND GND 12V
5
GND GND GND GND GND
6
FA+5 FA+5 FA+5 FA+5 FA+5
