Passport 8/12 Service Manual 1-3
1.2 Equipment Symbols
Some symbols may not appear on your equipment.
Caution
Refer to instruction manual/ booklet
Power ON/OFF (for a part of the
equipment)
Battery indicator
Alternating current
VGA output
Equipotentiality
Graphical record
USB connector
Network connector
Zero key Input/Output
Check sensor
Calibrate key
Measure/standby
Inserted direction
Gas outlet
Serial number
DATE OF MANUAFACTURE
Symbol for “MANUFACTURER”
Catalog number
Protected against vertically falling
water drops per IEC 60529
Electrostatic sensitive devices
DEFIBRILLATION-PROOF TYPE CF APPLIED PART
DEFIBRILLATION-PROOF TYPE BF APPLIED PART
The presence of this label indicates the machine was certified by ETL with the statement:
Conforms to AAMI Std ES 60601-1, IEC Std 60601-1-6, IEC Std 60601-1-8, IEC Std 60601-2-25, IEC Std
60601-2-26, IEC Std 60601-2-27, IEC Std 60601-2-34, IEC Std 60601-2-49, IEC Std 80601-2-30, ISO Std
80601-2-55, ISO Std 80601-2-56, ISO Std 80601-2-61
Certified to CSA Std C22.2 NO. 60601-1, NO. 60601-6, NO. 60601-1-8, NO. 60601-2-25, NO.
60601-2-26,NO. 60601-2-27, NO. 60601-2-34, NO. 60601-2-49, NO. 80601-2-30, NO. 80601-2-55, NO.
80601-2-56, NO. 80601-2-61
