8-14 Passport 8/12 Service Manual
8.3.2 Front Housing Subassembly
8.3.2.1 Exploded View
8.3.2.2 Parts List
SN Description FRU part number
1 PP12 Front cover(silk screen) 115-022925-00
27 Alarm lamp gasket
2 Alarm light of Passport 8
28 Long gasket, Passport 12, touchscreen
29 Short gasket, Passport 12, touchscreen
4 Long gasket, Passport 12, touchscreen
15 Square foot pad
6 Locking plate
26 Tube, white, 1.6 mm OD × 0.8 mmID
25 Alarm lamp board PCBA 051-000879-01
3 Knob of Passport 8 043-003641-00
7 Encoder board 0010-30-43089
10 Encoder cable 9200-21-10460
15 Wi-Fi module kit 115-010801-00 (2.4GHz)) or
115-034776-00 (5GHz)
Cyberlink module PCBA 051-000811-00 (2.4GHz)
Antenna cable 0012-00-1730-01 (2.4GHz)
