cOPILOT FEATURES AddINg REmOTES
14
SYSTEM FEATURES
CoPilot for Riptide ST setup and use instructions
• Your motor is factory installed with CoPilot for Riptide ST.
• Wireless control for Riptide ST.
• Plug – n – play design allows for easy hook-up.
• Functions include steering (right/left), prop (on/off), AutoPilot (on/off), high speed bypass, and speed control.
• Receiver mounts into the right side plate of the Riptide ST motor for seamless installation.
• Remote allows motor to be controlled from anywhere in the boat.
• Copilot Riptide ST can be used with or without the corded foot pedal.
• Remote will not interfere with Autopilot or Universal Sonar Operation.
• Up to 10 remotes can be used interchangeably with the same receiver.
• Components are environmentally sealed to protect against rain, wind, or snow.
ADDING / REMOVING REMOTES
• To “learn” the ID number of additional remotes, follow these steps:
1.) The system ready light must be on. To do so; push in the release handle and rotate it down.
2.) Press and hold the LEARN button located on the side of the receiver (receiver will emit a continuous tone.)
A small blunt object must be used to depress the LEARN button ( pen or screwdriver.)
3.) Press any button on the remote (receiver will beep 4 times confirming that it has “learned” the ID number of
the remote and that the programming is valid and complete.)
• “Re-learning” the ID number of the same remote will not overwrite previously “learned” remotes.
• If the receiver has “learned” the ID number of ten remotes, “learning” an eleventh remote will erase or over write the first
“learned” remote.
• The CoPilot allows the angler to erase all stored remote ID numbers from the receiver. To do so, follow these steps:
1.) Remove power from the receiver by stowing the motor.
2.) Press and hold the LEARN button and power up the receiver by pushing in the release handle and rotate it
down. Hold the LEARN button down for 10 seconds. During this time the receiver audio will emit a warble
sound, slowly transition to a constant beep and then shut off.
3.) Release the Learn button and the receiver will reboot. The receiver will emit a 2 second long beep indicating
memory is empty. This audio pattern will occur each time the receiver powers up until a remote ID number is
learned.
THE COPILOT RECEIVER IN THIS KIT HAS ALREADY “LEARNED” THE ID NUMBER OF THE REMOTE IT IS
PACKAGED WITH. THE RECEIVER MUST “LEARN” THE ID NUMBER OF ANY ADDITIONAL REMOTE(S) THAT
YOU INTEND TO USE. WHEN THE RECEIVER LEARNS THE ID NUMBER OF A REMOTE, THAT ID NUMBER
IS RETAINED IN THE RECEIVER EVEN WHEN THE MOTOR IS DISCONNECTED FROM ITS POWER SOURCE.
Learn Button
